Lockheed Martin F-16C/D Fighting Falcon

Origin
USA
Type
single-seat air-combat and multi-role fighter
Max Speed
1,146 kt / 1,320 mph
Max Range
3,886 km / 2,415 miles
Dimensions
span 10.00 m / 32 ft 9.75 in length 15.03 m / 49 ft 4 in height 5.09 m / 16 ft 8.5 in
Weight
empty 8,273 kg / 18,218 lb max. take-off 19,187 lb
Powerplant
one 13154-kg (29,000-lb) afterburning thrust Pratt & Whitney F100-PW-229 or General Electric F110-GE-129 turbofan
Armament
one 20-mm M61A1 Vulcan cannon with 500 rounds, plus provision for up to 9276 kg (20,450 Ib) of externa ordnance on one underfuselage, six underwing and two tip hardpoints, this total declining to 5420 kg (11,950 Ib) for sorties including 9-g manoeuvres; the ordnance can include AIM-9 Sidewinder and AIM-120 AMRAAM air-to-air missiles, a wide range of disposable ordnance (free-tall and guided), drop tanks and electronic pods (ECM, reconnaissance and targeting)
Operators:
Bahrain, Chile, Egypt, Greece, Israel, Iraq (36 Aircraft Ordered), South Korea, Morocco, Oman, Pakistan, Poland, Singapore, United Arab Emirates, Turkey, United States
Aircraft Overview:

The F-16 Fighting Falcon is the first operational fighter to employ fly-by-wire flight controls, relaxed static stability, high-g cockpit, bubble canopy, variable camber wings, blended wing-body design, modular construction, and integrated digital avionics.
