SAAB 35 Draken
single-seat interceptor
Specifications
- Origin
- Sweden
- Type
- single-seat interceptor
- Maximum Speed
- 1,146 kt / 1,320 mph
- Maximum Range
- 560 km / 348 miles
- Dimensions
- span 9.40 m / 30 ft 10.1 in
length 15.35 m / 50 ft 4.3 in
height 3.89 m / 12 ft 9.1 in - Weight
- empty 7,425 kg / 16,369 lb
max. take-off 16,000 kg /
35,274 lb - Powerplant
- one 7830-kg (17,262-lb) afterburning thrust Volvo Flygmotor RM6C turbojet
Armament
one 30-mm Aden M/55 cannon with 90 rounds, and two radar-homing Rb27 and two IR-homing Rb28 Falcon AAMs, or two or four Rb74 Sidewinder AAMs, or up to 4082 kg (9,000 Ib) of bombs in an attack mission
